Description

Electronic Rapid Start Ballast (for 2-pin and 4-pin Lamps), 280mA nominal lamp current, Input voltage of 120Vac (+/-10%), for 1 13W-17W Lamp, 47-63Hz.

PERFORMANCE:
- Power Factor = >0.50
- Encased & Potted
- Sound Rated A
- Internal Surge Protection
- Meets FCC Part 18 (Class B) for EMI and RFI Consumer Limits
- Meets ANSI Standard C62.41 for Transient Protection
- Meets ANSI Standard C82.11 for Ballast Requirements

APPLICATION:
- Maximum Case Temperature: 167F/75C
- Maximum Ambient Temperature: 122F/50C
- Minimum Starting Temperature: 23F/-5C
- Remote Mounting: 18 ft. Max. Lead Length, 18AWG

SAFETY/STANDARDS:
- UL/935 Listed (Class P, Type 1 Outdoor)
- cUL (CSA/C22.2 Certifi ed)
- No PCBs, Type HL, Type CC
- Inherent Thermal Protection
- RoHS Compliant

Specs

Ballast Type Electronic
Starting Method Preheat Rapid Start
Unit Color Galvanneal
Input Voltage 120Vac 10%
Lamp Connection Series
Input Frequency 47-63Hz

Lamp Compatibility

- G15T8/OF
- GCF13DS/GX23/OF
- HNS S 13 W GX23
- HNS 15W G13
- TUV T8 F17 1SL
- TUV PL-S 13W/2P
- TUV 15W SLV
- 21259 Osram HNS 15W G13
- 59156 Osram HNS S 13 W GX23

Data Sheet
