USHIO G16T5 16W Germicidal Low Pressure Mercury-Arc Lamp

USHIO Germicidal lamps are Low-Pressure Mercury-Arc lamps that emit radiation
peaking at 253.7nm(UV-C). This output at 253.7nm is highly effective to inactivate
microorganisms such as bacteria, virus, yeast and mold.

Features:
- Low Mercury dose to meet environmental demands
- Specially Formulated coating achieves high output over long life hours.
- High Purity lamp construction to stabilize UV output and minimizes depreciation (averages 20-25% depreciation at end of life)
- Flexible design capability for custom development.
- Spectral Peak: 253.7nm

- EPA Approved: Ushio EPA # Est.96093-JPN-1
Applications:
- Drinking Water
- Wastewater
- Air Conditioning System
- Medical Facilty
- Pharmaceutical Production Facility
- Food Processing Facility
- Packaging Materials
- Laboratory / Research
- Photochemistry
- Phototherapy
- Dermatology
- Clean room
- Other Sterilization and Disinfection needs

Manufacturer	Ushio
NAED	3000311
UPC	048777373354
Base	G5 2-Pin
Bulb Type	High Intensity Discharge Bulbs (HID)
Diameter (in)	0.61
Maximum Overall Length (in)	11.29
Rated Life (Hours)	8000
Wattage (W)	16W
EPA Approved	Ushio EPA # Est.96093-JPN-1

Manual:

Ushio Germicidal Low Pressure Mercury Arc Specs
